0660D010BH4HC Hydraulic Filter
- 0660D010BH4HC
- 01253050
- 01253106
- 01307725
- 02055975
- 1253050
- 1253106
- 1307725
- 2055975
Lvda 0660D010BH4HC hydraulic filter replacement is built to offer equal or better filtration performance based on the original OEM filter specifications.
7*24 Customer Service. Shipped Within 3 Days.
0660D010BH4HC is a high-performance, high-pressure hydraulic filter element. It is designed for inline pressure filters to capture particulate contamination and protect sensitive downstream components like proportional or servo valves.
0660: Size / Flow Rating (Nominal flow capacity around 660 L/min).
D: Pressure Filter Element (Designed for high-pressure housings like DF, DFF, or LF series).
010: Filtration Rating of 10 microns (μm) absolute.
Specification
| Dimension 1 (D1) | Dimension 2 (D2) | Height 1 (H1) | Height 2 (H2) |
| 90.0 mm | 47.0 mm | 330.0 mm | 324.0 mm |
Our hydraulic filter is indicated as a replacement and is not manufactured by or affiliated with the OEM or Brand listed. Part numbers and names are used for cross reference only. The element may vary from the image displayed on the left.
| OEM Brand | Model Number |
|---|---|
| HIFI | SH 75061 |
| AIRFIL | AFKOVL26910KP |
| BEHRINGER | BE660P12AH |
| DONALDSON | 589.52 , P170597 |
| EPPENSTEINER | 9.660LAH10SLF000P , 9.660LAH10XLF000P , E400HL660H102LLLA |
| FILTER MART | 050106 , 051312 , 289602 |
| FILTRATION GROUP | 7889702 , 890024SMVST10NBR |
| FINN FILTER | FC7273A010BS , FFKPVL17273A10ABS |
| FLEETGUARD | HF30278 |
| HY-PRO | HP33DHL1412MB |
| ILVA | 7003222 |
| INTERNORMEN | 303305 , 02.0660D.10VG.HR.HC.E.P |
| LIEBHERR | 510661414 |
| MANN + HUMMEL | HD1066/1 |
| MP FILTRI | DP138A010AHP01 , MP9702 |
| NETSTAL | 9641450171 |
| PALL | HC2237FCS13H , HC2237FDS13H |
| PARKER | G03211 , PR3211 , PR3211Q |
| PUROLATOR | 0660EAH124N1 |
| QUALITY FILTRATION | QH661DA12B |
| REXROTH | 9.660LAH10XLF000M , 9660LAH10XLF000M , R928017412 |
| SANDVIK | 77011123 |
| SCHROEDER | SBF0661DS7B , SBF0661DZ10B |
| SEPARATION TECHNOLOGIES | H660D10H |
| SF-FILTER | HY13123 |
| SOFIMA HYDRAULICS | 30726 , SHD0660FD21 |
| STAUFF | SE160F10B4 , SE160H10B , SE160H10B4 |
| STEP FILTERS | HID42005 |
| VICKERS | V0664B2H10 |
