MF1001A25NB Hydraulic Filter Element
- MF1001A25NB
- MF1001A25HB
- MF1001A25HBP01
Lvda MF1001A25NB hydraulic filter replacement is built to offer equal or better filtration performance based on the original OEM filter specifications.
7*24 Customer Service. Shipped Within 3 Days.
Filter compatible with MF1001A25NB
Meets or exceeds OEM Standards.
Equipped with advanced filtration technology, these filters effectively remove particles, dirt, and impurities from hydraulic fluids or oil, preventing damage to critical components.
Designed for various applications, including hydraulic systems and oil filtration.
Specification
| Efficiency | Outer Diameter | Inner Diameter | Length | Bypass Pressure |
| 20µ | 70.0 mm | 29.5 mm | 85.0 mm | 1.7 BAR |
Our hydraulic filter is indicated as a replacement and is not manufactured by or affiliated with the OEM or Brand listed. Part numbers and names are used for cross reference only. The element may vary from the image displayed on the left.
| OEM Brand | Model Number |
|---|---|
| DONALDSON | CR5003 , CR6003 , P171520 , P171526 |
| PARKER | 943710Q |
| AIRFIL | AFPOVL35325 |
| BEHRINGER | BEF100125A , BEF100125AV |
| DRONNINGBORG | 45145300 |
| FAI FILTRI | F6B25 |
| FILPRO | FP10-39369 , FP10-13070 , FP10-185086 |
| FILTER MART | 051261 , 285605 |
| FILTRATION GROUP | MP1001RN2025V1,7 |
| FLUITEK | FLK02-20720 |
| HY-PRO | HP15L3-25MB |
| IKRON | HHC01231 , HEK0520077ASFG025VMB17B , HHC01232 |
| JLG | 7040632 |
| LHA | TIE16BTA251 , TIE1625A1 , TIE1625P1 , TIE16BTA251 |
| MAIN FILTER | MF0062281 |
| MODINA | RE15FV1 |
| NATIONAL FILTERS | RFC120-3-25G-B |
| OMT | CR65H , CR111F25R , CR65HN , CR65B , CR65H |
| SCHROEDER | 3TBS15 , 3TBZ25 |
| SF-FILTER | HY18420 |
| SOFIMA | 48152 , CRE015CV1 , CRE015FV1 , RE15FV1 , TE19FV1 , CRE015FV1 , 48152FV , CRE015FV1M |
| SWIFT | SFMF2-3-25UM |
| UFI | ERA31NFD |
| ZINGA | Z3E30325 |
| FILTREC | R120G25B |
| HIFI | SH 63348 |
