933220Q Hydraulic Filter
- 933220Q
933220Q Hydraulic filter element is widely used in the hydraulic system, and lubricant system to filter the solid and colloidal particles, protect the system working safely and efficiently.
7*24 Customer Service. Shipped Within 3 Days.
Filter compatible with 933220Q
Meets or exceeds OEM Standards.
All filters are manufactured by an ISO Certified company.
Equipped with advanced filtration technology, these filters effectively remove particles, dirt, and impurities from hydraulic fluids or oil, preventing damage to critical components.
Our hydraulic filter is indicated as a replacement and is not manufactured by or affiliated with the OEM or Brand listed. Part numbers and names are used for cross reference only. The element may vary from the image displayed on the left.
Specification
| Outer Diameter | Inner Diameter | Overall Length | Efficiency Beta 1000 | Collapse Burst |
| 96.2 mm | 53.7 mm | 653.4 mm | 12 micron | 10.3 bar |
Our hydraulic filter is indicated as a replacement and is not manufactured by or affiliated with the OEM or Brand listed. Part numbers and names are used for cross reference only. The element may vary from the image displayed on the left.
| OEM Brand | Model Number |
|---|---|
| HYDAC | 10826D12BN , 02070196 |
| DONALDSON | P566507 |
| PALL | HC8900FDS26H , HC8900FDS26Z , HC8900FKS26H , HC8900FKS26Z , HC8900FUS26H , HC8900FUS26Z |
| MP FILTRI | MP3615 , PL0504A010ANP01 , MP5356 |
| HY-PRO | HP89L2612MB , HP89L2612MV |
| FLEETGUARD | HF30333 , HF30334 |
| STAUFF | SP180E10B |
| SCHROEDER | SBF890026S7B , SBF890026Z10B |
| WIX | D87A10G |
| MAIN FILTER | MF0059348 |
| SF | HY 20464 |
| HIFI FILTER | SH 87106 |
