Steel mills industry Hydraulic filter

Hydraulic Filter Cartridge P171745

P171745 Hydraulic Filter Cartridge, Synthetic Media, 23 um at Efficiency Beta 1000, 290 psi, 1.59 in ID, 3.07 in OD, 9.45 in Overall Height

P171747 Hydraulic Filter

P171747 Hydraulic Filter Cartridge, Synthetic Media, 11 um at Efficiency Beta 1000, 290 psi, 1.59 in ID, 3.07 in OD, 14.96 in Overall Height

P171819 Hydraulic Filter

P171819 Outer Diameter:106 mm (4.17 inch), Inner Diameter:64 mm (2.52 inch), Length:190 mm (7.48 inch), Efficiency Beta 1000:23 micron

Hydraulic Cartridge Filter P171873

P171873 Outer Diameter:94 mm (3.70 inch), Thread Size:1 BSP/G, Length:83 mm (3.27 inch), Efficiency Beta 2:90 micron

Hydraulic Filter Strainer P171885

P171885 Hydraulic Filter Strainer, Series: SEH Series, 1-1/4 in Port, BSP, G Port Connection, Wire Mesh Media, 90 um at Beta 2, 17.3 gpm Flow Rate, 250 deg F Operating, Stainless Steel Housing, Zinc-Plated Housing, 3.74 in OD, 6-3/4 in Overall Height

Hydraulic Filtration P171889

P171889 Hydraulic Filter Strainer, Series: SEH Series, 1-1/2 in Port, BSP, G Port Connection, Wire Mesh Media, 90 um at Beta 2, 22.6 gpm Flow Rate, 250 deg F Operating, Stainless Steel Housing, Zinc-Plated Housing, 5.39 in OD, 3.9 in Overall Height
