P171814 Hydraulic Filter Cartridge
- P171814
- CRS2801
P171814 is a cartridge hydraulic filter element (Hydraulic Filter Cartridge). It is mainly used for return oil filtration in construction machinery or hydraulic systems to protect system components from particles
7*24 Customer Service. Shipped Within 3 Days.
Filter compatible with P171814
Compatible with OEM filter in fit, form and function.
Equipped with advanced filtration technology, these filters effectively remove particles, dirt, and impurities from hydraulic fluids or oil, preventing damage to critical components.
Specification
| Outer Diameter | Inner Diameter | Length | Efficiency Beta 2 | Efficiency Beta 1000 | Collapse Burst |
| 106 mm (4.17 inch) | 64 mm (2.52 inch) | 465 mm (18.31 inch) | 7 micron | 23 micron | 10 bar (145 psi) |
Our hydraulic filter is indicated as a replacement and is not manufactured by or affiliated with the OEM or Brand listed. Part numbers and names are used for cross reference only. The element may vary from the image displayed on the left.
| OEM Brand | Model Number |
|---|---|
| BALDWIN | PT9189 |
| BUSSE | HE341 |
| DIAMOND | DHR0511 |
| DIGOMA | DGMH5A10 |
| HIFI | SH 56359 |
| FAI FILTRI | R2504P10A |
| FAIREY ARLON | TXX5A10 |
| FBN | HI104668 |
| FILTER MART | 280285 |
| FINN FILTER | FFPA11094A |
| FLEETGUARD | HF6309 |
| MAIN FILTER | MF0063487 |
| MP FILTRI | 64000022 , MR2504P10A , MR2504P10AP01 |
| NATIONAL FILTERS | RFC7201810PB |
| PARKER | 937727 , PR4404 , TXX5A10B |
| PUROLATOR | TX30EAL101N6 |
| SEPARATION TECHNOLOGIES | ST6309 |
| SF-FILTER | HY2811 |
| SOFIMA HYDRAULICS | CRC240CD1 , RC240CD1 , S5567PO |
| SOTRAS | H11230P10 , SH8028 |
| STAUFF | RA300L10B |
| UFI | 2556700 , ERF24NCC |
| VICKERS | FT2504P10A |
| WOODGATE | WGTX5A10 |
